Htouch6N CP21-66H 675-695W

Hanersun Technology Co., Ltd

Typ:	Monokristallin
Leistungsbereich:	Wp
Region:	China

Das Produkt wird nicht mehr hergestellt.

Alternativprodukt

GSM-MH5/132- H...

Grand Sunergy

Zellentyp: HJT
Abmessungen: 1924x1038x35 mm
Gewicht: 27 kg
Zellengröße: --
Glasstärke: --

Mehr

Produktinformation
Firmenprofil

Produkteigenschaft

Modelnummer

CP21-66H675W

CP21-66H680W

CP21-66H685W

CP21-66H690W

CP21-66H695W

Garantie

Produktgarantie

12 Jahre

Leistungsgarantie

25 Jahre auf 89,4% der angegebenen Nennleistung

Elektrische Daten bei STC

Nennleistung (Pmax)

675 Wp

680 Wp

685 Wp

690 Wp

695 Wp

Spannung bei Maximalleistung (Vmpp)

39,4 V

39,6 V

39,8 V

40 V

40,2 V

Strom bei Maximalleistung (Impp)

17,14 A

17,18 A

17,22 A

17,25 A

17,29 A

Leerlaufspannung (Voc)

47,2 V

47,4 V

47,6 V

47,8 V

48 V

Kurzschlussstrom (Isc)

18,14 A

18,18 A

18,22 A

18,26 A

18,3 A

Modulwirkungsgrad

21,73 %

21,89 %

22,05 %

22,21 %

22,37 %

Standard Testbedingungen (STC): Luftmasse AM 1,5 - Einstrahlung 1000 W/m² - Zellentemperatur 25°C,

Elektrische Daten bei NOTC

Nennleistung (Pmax)

513 Wp

516 Wp

523 Wp

527 Wp

530 Wp

Spannung bei Maximalleistung (Vmpp)

36,9 V

37,1 V

37,3 V

37,5 V

37,7 V

Strom bei Maximalleistung (Impp)

13,89 A

13,92 A

14,01 A

14,04 A

14,07 A

Leerlaufspannung (Voc)

44,7 V

44,9 V

45,1 V

45,3 V

45,5 V

Kurzschlussstrom (Isc)

14,62 A

14,65 A

14,68 A

14,71 A

14,74 A

Temperatur

43±2 °C

Norminal operating cell temperature (NOCT): Einstrahlung 800 W/m², AM 1,5 – Umgebungstemperatur 20°C – Windgeschwindigkeit 1 m/s

Thermische Daten

Temperaturbereich

40~85 °C

Temperaturkoeffizient Pmax

0,31 %/°C

Temperaturkoeffizient Voc

0,25 %/°C

Temperaturkoeffizient Isc

0,04 %/°C

Parameter der Systemintegration

Maximale Systemspannung

1500 V

Rückwärtsbestromung

35 A

Technische Daten

Modulabmessungen (H/B/T)

2384x1303x35 mm

Gewicht

34,4 kg

Zellentyp

Monokristallin

Zellenzahl

132

Glastyp

Entspiegelt, Temperiert

Glasstärke

3,2 mm

Verkapselung

EVA

Frame-Typ

Eloxiertem Aluminiumlegierung

IP Schutzgrad

IP 68

Steckertyp

MC4

Kabelquerschnitt

4 mm²

Kabellänge

300 mm
