HRAP-108H 400-420M10

Jiangsu Apex Solar Energy Technology Co., Ltd.
Typ: Monokristallin
Leistungsbereich: 400 ~ 420 Wp
Region: China China
Hinweis: Ihre Anfrage wird direkt an Jiangsu Apex Solar Energy Technology Co., Ltd. gesendet.


Monocrystalline module series with a maximum efficiency of 21.48%

Half-cut modules with 6 cell strings

Incorporates multi-busbar technology

Equipped with an anti-reflection coating to reduce the reflectivity of the front glass

Strict electroluminescence testing


400 405 410 415 420
Produktgarantie 12 Jahre
Leistungsgarantie 25 Jahre auf 84,8% der angegebenen Nennleistung
Elektrische Daten bei STC
Nennleistung (Pmax)
400 Wp 405 Wp 410 Wp 415 Wp 420 Wp
Spannung bei Maximalleistung (Vmpp)
30,75 V 31 V 31,25 V 31,49 V 31,73 V
Strom bei Maximalleistung (Impp)
13,01 A 13,07 A 13,12 A 13,18 A 13,24 A
Leerlaufspannung (Voc)
36,75 V 37 V 37,25 V 37,5 V 37,75 V
Kurzschlussstrom (Isc)
13,76 A 13,83 A 13,88 A 13,94 A 14,01 A
20,46 % 20,72 % 20,97 % 21,23 % 21,48 %
Leistungstoleranz (+)
+ 0,5 % + 0,5 % + 0,5 % + 0,5 % + 0,5 %
  Standard Testbedingungen (STC): Luftmasse AM 1,5 - Einstrahlung 1000 W/m2 - Zellentemperatur 25°C,
Elektrische Daten bei NOTC
Nennleistung (Pmax)
299 Wp 302,7 Wp 306,5 Wp 310,2 Wp 313,9 Wp
Spannung bei Maximalleistung (Vmpp)
28,56 V 28,8 V 29,03 V 29,25 V 29,47 V
Strom bei Maximalleistung (Impp)
10,47 A 10,52 A 10,56 A 10,6 A 10,65 A
Leerlaufspannung (Voc)
34,55 V 34,79 V 35,08 V 35,26 V 35,49 V
Kurzschlussstrom (Isc)
11,13 A 11,18 A 11,22 A 11,27 A 11,32 A
Temperatur 45±2 °C
  Norminal operating cell temperature (NOCT): Einstrahlung 800 W/m2, AM 1,5 – Umgebungstemperatur 20°C – Windgeschwindigkeit 1 m/s
Thermische Daten
Temperaturbereich 40~85 °C
Temperaturkoeffizient Pmax 0,34 %/°C
Temperaturkoeffizient Voc 0,28 %/°C
Temperaturkoeffizient Isc 0,05 %/°C
Parameter der Systemintegration
Maximale Systemspannung 1500 V
Rückwärtsbestromung 25 A
Technische Daten
Modulabmessungen (H/B/T) 1724x1134x30 mm
Gewicht 21,5 kg
Zellentyp Monokristallin
Zellenzahl 108
Glastyp Entspiegelt, Temperiert
Glasstärke 3,2 mm
Frame-Typ Eloxiertem Aluminiumlegierung
IP Schutzgrad IP 68
Kabelquerschnitt 4 mm2
Kabellänge 300 mm
